U-Nano ultra-micro plate
Convenient for high throughput micro nucleic acid quantification
(1) No need to dilute samples, the whole board takes only 3 to 5 seconds to read
(2) Measure 1~16 samples at once, only need 2 ul
(3) For continuous testing, only need to wipe off the previous batch of samples with dust-free paper
(1) Incubation temperature: RT. +4C-50C;
(2) Average temperature difference between well at 37℃
is 土0.5°C; plate temperature uniformity: <1.0℃(96-well plate without cover)
(3) Perform onboard linear shaking, low（5hz）, medium（11hz）, high speed（20hz）available.
(1) Suitable for 6, 96, 384-well, ultra-micro plate, cuvette (UReader-Eyes C), a variety of options to suit your experimental needs
(2) Separate cuvette slot, motor-driven, no need mannual switch, convenient and accurate
(1) 190-1000 nm full-wavelength design with 1nm step. Grating monochromator is used, multiple choice, more suitable for all kinds of experiments
(2) Long life xenon lamp is used as light source. Grating monochromator optical path detection system ensures excellent wavelength accuracy of the instrument
(3) Power-on self-check function, auto-check the light source, detector, carrier position and other key components to ensure the stable and reliable operation of the instrument
(4) Double beam optical system, with reference optical path channel system, to ensure more stable detection data.
Easy-to-use operation interface
(1) 12-inch high resolution LCD touch screen
(2) Several languages available: Chinese and English; Data export flexibility: USB export or directly export to EXCEL
(3) Visualization layout the microplate, can quickly label blank, sample, positive and negative control and quality control, support multi-value control
(4) Various testing programs can be preset, single plate can be tested for a number of different inspection items.
(1) Directly connect PC via WIFi, save laboratory space, convenient for your laboratory planning
(2) Built-in standard curve library, when doing experiment, one can use the saved curve directly;
(3) Built-in data analysis software, support stand-alone operation and PC control via UReader-Eyes software.
(1) You need to perform spectral scanning of high flux samples
(2) Your sample's absorption peak is different from commonly used filters, or your laboratory needs to detect multiple different wavelengths
(3) This instrument supports routine laboratory testing items such as cell proliferation, cell apoptosis, enzyme kinetics, and GPCR analysis.
